4 Installing a Video Printer
If a multiformat camera is not connected 1
Power cable 1
Videoprinter with 100VAC line voltage:
Connect the line wires to transformer T1, connector TI - 34 and TI - 36.
Connect the protective conductor to the protective conductor terminal stripe (ye/gn).
Videoprinter with 120VAC line voltage:
Connect the line wires to transformer T1, connector TI - 35 and TI - 36.
Connect the protective conductor to the protective conductor terminal stripe (ye/gn).
Videoprinter with 230VAC line voltage:
• Connect the line wires of the video printer at terminals X2.1 and X2.2.
• Connect the protective conductor at the corresponding location (yellow/green).
• Route the line wires to the video printer compartment.
Hardcopy exposure control cable 1
• Connect the control cable included with the shipment at the Memoskop "Printer"
connector.
• Route the end of the cable with the 3.5 mm jack plug to the video printer compartment.
Video cable 1
• Connect the video cable at the Memoskop "Out3" connector.
• Route the video cable to the video printer compartment.
• Connect the video printer. Ensure the proper termination of the video cable
(75 ohm).
Programming 1
For Memoskop C (with keyboard)
• Switch on the system.
• Press [CTRL] and [U] simultaneously on the Memoskop keyboard.
 This calls the "User Setup menu" for Memoskop.
• Call up the "C Documentation" sub-menu.
• Perform the configuration on monitor A for SIREMOBIL Iso-C systems with one monitor.
• Perform the configuration on monitor B for SIREMOBIL Iso-C systems with two monitors.
• If the system is equipped with an area dose measurement device (Diamentor), call up
the "K documentation of the dose" sub-menu and configure to "yes".
• End the "User menu".
