Siemens SIRIUS 3RW5 Equipment Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus communication module
162 Equipment Manual, 03/2020, A5E43676481002A/RS-AC/003
A.2.17 Maximum pointer
Only read access (r) to the maximum pointers is possible via Function Codes 03 and 04.
Register
Byte
Data format
Maximum pointer
Range of values
In steps of
3RW
Address
high /
low
50 /
52
1)
55 /
55-F
2)
0x9001
[36865]
high Unsigned8 Phase current I L1 min (%) 0 … 796.9 % 3.125 % r r
low
Unsigned8
Phase current I L2 min (%)
0 … 796.9 %
3.125 %
r
r
0x9002
[36866]
high Unsigned8 Phase current I L3 min (%) 0 … 796.9 % 3.125 % r r
0x9003
[36867]
high
Unsigned8
Phase current I L1 max (%)
0 … 796.9 %
3.125 %
r
r
low Unsigned8 Phase current I L2 max (%) 0 … 796.9 % 3.125 % r r
0x9004
[36868]
high Unsigned8 Phase current I L3 max (%) 0 … 796.9 % 3.125 % r r
0x9005
[36869]
high Unsigned16 Maximum trigger current 0 … 1000 % 3.125 % r r
0x9006
[36870]
high Unsigned16 Number of motor overload trips 0 … 65 535 1 r r
0x9007
[36871]
high Signed32 Maximum trigger current -20 000 …
20 000 A
0.01 A r r
0x9009
[36873]
high Signed32 Phase current I L1 min (rms) -20 000 …
20 000 A
0.01 A r r
0x900B
[36875]
high Signed32 Phase current I L2 min (rms) -20 000 …
20 000 A
0.01 A r r
0x900D
[36877]
high Signed32 Phase current I L3 min (rms) -20 000 …
20 000 A
0.01 A r r
0x900F
[36879]
high Signed32 Phase current I L1 max (rms) -20 000 …
20 000 A
0.01 A r r
0x9011
[36881]
high Signed32 Phase current I L2 max (rms) -20 000 …
20 000 A
0.01 A r r
0x9013
[36883]
high Signed32 Phase current I L3 max (rms) -20 000 …
20 000 A
0.01 A r r
0x9015
[36885]
high Unsigned16 Line voltage U L1-L2 min 0 … 1 500 V 0.1 V - r
0x9016
[36886]
high Unsigned16 Line voltage U L2-L3 min 0 … 1 500 V 0.1 V - r
0x9017
[36887]
high Unsigned16 Line voltage U L3-L1 min 0 … 1 500 V 0.1 V - r
0x9018
[36888]
high Unsigned16 Line voltage U L1-L2 max 0 … 1 500 V 0.1 V - r
0x9019
[36889]
high Unsigned16 Line-to-line voltage U L2-L3 max 0 … 1 500 V 0.1 V - r
0x901A
[36890]
high Unsigned16 Line voltage U L3-L1 max 0 … 1 500 V 0.1 V - r
0x901D
[36893]
low Unsigned8 Maximum switching element heating 0 … 250 % 1 % r r
