Performing basic parameterization

6.3 Drive axes

148 Getting Started, 12/2018, 6SL3097-5AG30-0BP0

6.3.2

VECTOR drives

6.3.2.1

Basic parameterization of the drive axes

During the basic configuration, not all of the available options are displayed in the drop-down

list "Basic parameterization". The following table lists the available options for the basic

parameterization of a VECTOR drive axis or axes – and the dependency regarding display

and selectability of options during the basic parameterization.

Note

Dynamic display of options

The display of certain options is dynamic, and depends on the settings, which are carried out

within another option other than the required option. In the "Basic parameterization" list, the

"Mechanical system" option is only displayed if beforehand, the "Basic positioner" function

module was acti

vated (see Chapter "Function modules (Page 148)").

Precondition

● The VECTOR drive axis is OFFLINE.

6.3.2.2

Function modules

☐

"Drive axis > Parameters > Basic parameterization > Function modules"

When required, during the basic parameterization you can switch-in various function

modules for the selected drive axis.

Note

You can only activate and deactivate function modules OFFLINE.

Note

The display of the function modules that can be activated is dynamic and depends on the

selected drive axis and the configuration of this drive axis.
