Siemens SIROTEC Getting Started

Preface
Getting Started, 12/2018, 6SL3097-5AG30-0BP0
5
Where can the various topics be found?
Software
Manual
Alarms
Described in order of ascending numbers
SINAMICS S120/S150 List Manual
Parameters Described in order of ascending numbers SINAMICS S120/S150 List Manual
Function block
diagrams
Sorted according to topic
SINAMICS S120/S150 List Manual
Described in order of ascending numbers
Drive functions
SINAMICS S120 Function Manual Drive Functions
Communication topics SINAMICS S120 Function Manual Communication (from
firmware V5.2)
Safety Integrated Basic and Extended Functions SINAMICS S120 Safety Integrated Function Manual
Basic Functions
SINAMICS S120 Function Manual Drive Functions
Commissioning Of a simple SINAMICS S120 drive with
STARTER
Getting Started (up to Firmware V5.1 SP1)
Commissioning With STARTER SINAMICS S120 Commissioning Manual (up to firmware
V5.1 SP1)
Commissioning Of a simple SINAMICS S120 drive with
Startdrive
Getting Started (from Firmware V5.2)
Commissioning With Startdrive SINAMICS S120 Commissioning Manual (from firmware
V5.2)
Web server
SINAMICS S120 Function Manual Drive Functions
Hardware
Manual
Control Units And expansion com-
ponents:
• Control Units
• Option Boards
• Terminal Modules
• HUB Modules
• VSM10
• Encoder system
connection
SINAMICS S120 Equipment Manual for Control Units
and Additional System Components
Power units
booksize
• Line connection
• Line Modules
• Motor Modules
• DC link compo-
nents
• Braking resistors
• Control cabinet
design
SINAMICS S120 Equipment Manual for Booksize
Power Units
Power units, booksize C/D type format SINAMICS S120 Equipment Manual for Booksize
Power Units
C/D Type
Chassis power units SINAMICS S120 Equipment Manual for Chassis Power
Units, Air-cooled or Liquid-cooled
AC drive components
SINAMICS S120 Equipment Manual for AC Drives
S120 Combi components
SINAMICS S120 Equipment Manual Combi
Diagnostics via
LEDs
STARTER SINAMICS S120 Commissioning Manual (up to firm-
ware V5.1 SP1)
Startdrive SINAMICS S120 Commissioning Manual (from firm-
ware V5.2)
