SITOP PSU100L

Manual, 08.2016, C98130-A7603-A1-2-7629

Description, device design, dimension drawing

2.1

Device description

SITOP PSU100L is a primary-clocked power supply for connection to a 1-phase AC line

supply. An electronically regulated DC voltage that can be set via a potentiometer is

available at the output of the device. The output of the device is isolated, no-load proof and

short-circuit proof. The LED display is used to signal the operating state.

①

AC input

②

DC output

③

Potentiometer U

out

④

Indicator light (24 V O.K.)

⑤

Voltage selector switch

⑥

DIN rail slider

⑦

Natural convection

⑧

Clearance above/below

Figure 2-1 Design (example, 6EP1334-1LB00)
