2 Key Features of the TC65 Terminal
Feature Implementation
General
Incorporates TC65
module
The TC65 module handles all processing for audio, signal and
data within the TC65 Terminal. Internal software runs the
application interface and the whole GSM protocol stack.
Frequency bands Quad band: GSM 850/900/1800/1900MHz
GSM class Small MS
Output power
(according to
Release 99, V5)
Class 4 (+33dBm ±2dB) for EGSM850
Class 4 (+33dBm ±2dB) for EGSM900
Class 1 (+30dBm ±2dB) for GSM1800
Class 1 (+30dBm ±2dB) for GSM1900
The values stated above are maximum limits. According to
Release 99, Version 5, the maximum output power in a multislot
configuration may be lower. The nominal reduction of maximum
output power varies with the number of uplink timeslots used and
amounts to 3.0dB for 2Tx, 4.8dB for 3Tx and 6.0dB for 4Tx.
Power supply Single supply voltage 8V to 30V
Operating temperature
-30°C to +65°C ambient temperature
Physical
Dimensions: 130mm x 90mm x 38mm
Weight: approx. 190g
RoHS, WEEE
All hardware components are fully compliant with the EU RoHS
and WEEE Directives
GSM / GPRS features
Data transfer GPRS
• Multislot Class 12
• Full PBCCH support
• Mobile Station Class B
• Coding Scheme 1 – 4
CSD
• V.110, RLP, non-transparent
• 2.4, 4.8, 9.6, 14.4kbps
• USSD
PPP-stack for GPRS data transfer
