TC65 Terminal Hardware Interface Description
Confidential / Released
s
TC65 Terminal_HD_V02.000b Page 40 of 65 2007-02-19
SPI MODE 0 SPI MODE 1
SPI MODE 2 SPI MODE 3
Clock phase
Clock polarity
SPICS
SPIDO
SPICLK
SPIDI
SPICS
SPIDO
SPICLK
SPIDI
SPICS
SPIDO
SPICLK
SPIDI
SPICS
SPIDO
SPICLK
SPIDI
Sample Sample
Sample Sample
Figure 12: Characteristics of SPI modes
