System overview
10
Building Technologies
A6V10099835_a_en
Fire Safety & Security Products 12.2007
3.1 Configuration of the system
Every extinguishing system is individually configured. The configuration has an
effect on operation. The following table shows the configuration of your automatic
extinguishing system.
Function Configuration
Activation of access level 2 [ ] using standard access code
[ ] using individual access code
Setting of activated time ........ seconds
Setting of flooding time ........ seconds
State “Fire alarm“ [ ] slow pulsating
[ ] continuous
[ ] not activated
State “Activated“ [ ] continuous
[ ] pulsating
Sound mode of alarm horn
State “Released“ [ ] pulsating
[ ] continuous
Fixed running time of alarm horn [ ] yes ........minutes
[ ] no
Reminder beep every 4 minutes upon "Fault"
and "Part of system off"
[ ] activated
[ ] not activated
Emergency hold button installed [ ] yes
[ ] no
Emergency abort button installed [ ] yes
[ ] no
Other blocking devices .....................................................................
Extinguishing agent monitoring [ ] yes
[ ] no
Pressure switch for state "Released" [ ] yes
[ ] no
Trigger condition for automatic activation of
extinguishing
[ ] Detector zone 1 or 2
[ ] Detector zone 1 and 2
[ ] Detector zone 1 and 2 and 3
Alarm verification activated [ ] yes
[ ] no
Direct remote transmission [ ] yes
[ ] no
[ ] fire alarm
[ ] activated
[ ] extinguishing activated
[ ] fault
Transmission to the fire detection control unit [ ] yes
[ ] no
[ ] fire alarm
[ ] activated
[ ] extinguishing activated
[ ] fault
[ ] blocked
Maximum operating time in the event of mains
power failure
........ hours
Fault delay in the event of power failure ........ minutes
System reset not possible as long as alarm
horn or manual release button or pressure
switch (released) is active
[ ] yes
[ ] no
Faults must be reset after being eliminated [ ] yes
[ ] no
