BAT NORMAL => BAT LOW 15% yellow scale
BAT LOW => BAT CRITICAL 5% red scale
BAT CRITICAL => BAT EMPTY 0% red outline
Rising voltage:
BAT EMPTY => BAT CRITICAL 2% red scale
BAT CRITICAL => BAT LOW 7% yellow scale
BAT LOW => BAT NORMAL 17% green scale
BAT NORMAL => BAT FULL 97% green full scale
If one of the two batteries is removed, the indicated SOC level will be
halved and the warning “BATTERY LOST” will be set (D10 only).
If the SOC level of the two batteries differs more than 15%, the warning
“UNBALANCED” will be set (D10 only).
Service messages are sent when the SOC level falls below the BAT LOW
or BAT CRITICAL levels.
For replacement of the backup battery, send the instrument to Sigicom.
