110 SDG1000X User Manual
2.13.6 Remote Interface
The SDG1000X can be controlled remotely via USB, LAN and GPIB (option)
interfaces. Users can set the corresponding interface according to their needs.
Press Utility → Page 1/2 → Interface to open the following menu. The user
can set LAN parameters or GPIB address.
Figure 2-66 Interface Settings
Table 2-39 Menu Explanations of Interface
Function
Menu
Settings
Explanation
GPIB
Set the GPIB address.
LAN State
On
Turn on LAN.
Off
Turn off LAN.
LAN Setup
Set the IP address, subnet mask and gateway.
Accept
Save the current settings and return to the Utility
menu.
The SDG1000X can be controlled remotely via the following two methods:
1. User-defined programming
Users can program and control the instrument by using the SCPI commands
