3.4 Example 4: Generate a Pulse Waveform
Generate a pulse waveform with 5kHz frequency, 5V high level, -1V low level,
40μs pulse width and 20ns delay.
 Steps:
 Set the Frequency.
1. Press Waveforms → Pulse → Frequency/Period and choose Frequency,
which will display in blue color.
2. Input ‗5‘ from the keyboard and choose the unit ‗kHz‘. The frequency is set
to 5 kHz.
 Set the HighLevel.
1. Press Amplitude/HighLevel and choose the HighLevel which will display in
blue color.
2. Input ‗5‘ from the keyboard and choose the unit ‗V‘. The high level is set to
5V.
 Set the LowLevel.
1. Press Offset/LowLevel and choose the LowLevel which will display in blue
color.
2. Input ‗-1‘ from the keyboard and choose the unit ‗V‘. The low level is set to
-1V.
 Set the PulWidth.
1. Press PulWidth/DutyCycle and choose PulWidth which will display in blue
color.
2. Input ‗40‘ from the keyboard and choose the unit ‗μs‘. The pulse width is
set to 40μs.
 Set the Delay.
1. Press Delay to choose Delay which will display in blue color.
