SDG1000X User Manual 125
3.2 Example 2: Generate a Square Waveform
Generate a square waveform with 5kHz frequency, 2Vpp amplitude, 1Vdc
offset and 30% duty cycle.
 Steps:
 Set the frequency.
1. Press Waveforms → Square → Frequency/Period and choose Frequency
which will display in blue color.
2. Input ‗5‘ from the keyboard and choose the unit ‗kHz‘. The frequency is set
to 5kHz.
 Set the Amplitude.
1. Press Amplitude/HighLevel to choose Amplitude which will display in blue
color.
2. Input ‗2‘ from the keyboard and choose the unit ‗Vpp‘. The amplitude is set
to 2Vpp.
 Set the Offset.
1. Press Offset/LowLevel to choose Offset which will display in blue color.
2. Input ‗1‘ from the keyboard and choose the unit ‗Vdc‘. The offset is set to
1Vdc.
 Set the DutyCycle.
1. Press DutyCycle to choose DutyCycle which will display in blue color.
2. Input ‗30‘ from the keyboard and choose the unit ‗%‘. The duty is set to
30%.
When the frequency, amplitude, offset and duty cycle are set, the waveform
generated is shown in Figure 3-2.
