SIGLENT
IV SDG1000X User Manual
Introduction to SDG1000X
The manual covers the following 2 models of SDG1000X Series
Function/Arbitrary Waveform Generators: SDG1032X and SDG1062X.
SIGLENT‘s SDG1000X is a series of dual-channel function/arbitrary waveform
generators with specifications of up to 60MHz maximum bandwidth, 150MSa/s
sampling rate and 14-bit vertical resolution. The proprietary EasyPulse
technology helps to solve the weaknesses inherent in traditional DDS
generators when generating pulse waveforms, and the special square wave
generator is capable of generating square waveforms with up to 60MHz
frequency and low jitter. With these advantages, the SDG1000X can provide
users with a variety of high fidelity and low jitter signals and can meet the
growing requirements of complex and extensive applications.
Key Features
Dual-channel，with bandwidth up to 60MHz and amplitude up to 20Vpp
150MSa/s sampling rate, 14-bit vertical resolution, and 16kpts waveform
length
Innovative Easy Pulse technology, capable of generating lower jitter Pulse
waveforms, brings a wide range and extremely high precision in pulse
width and rise/fall times adjustment
Special circuit for Square waves, which can generate Square wave with
frequencies up to 60MHz and jitter less than 300ps+0.05ppm of period
A variety of analog and digital modulation types: AM、DSB-AM、FM、PM、
FSK、ASK 、PSK and PWM
Sweep and Burst functions
Harmonic waveforms generating function
Waveforms combining function
