SIGLENT STB3 User Manual


9.6 kbps



LIN 2.0

NO.
Break
Sync
PID
Parity
Data
Checksum
Stop
1
≧13bit
8'h55
6'h06
2'b00
16'h54_5f
8'h46
T
2
≧13bit
8'h55
6'h14
2'b00
16'h54_5f
8'h38
T
3
≧13bit
8'h55
6'h25
2'b00
32'h45_4e_54_5f
8'h93
T
4
≧13bit
8'h55
6'h3b
2'b03
64'h53_49_47_4c_54_5f
8'h8c
T
Table 2 LIN Frame
Figure 35 LIN Signal
CAN

50 kbps



Extended format



ISO-11898-5 physical layer

NO.
SOF
ARB
RTR
r1
r0
DLC
Data
CRC
ACK
EOF
1
SOF
29'h7819
1'b0
1'b1
1'b1
4'h8
64'h53_49_47_4C_
15'h7541
D
EOF
f51
45_4E_54_5F
2
SOF
29'h12f3
1'b1
1'b1
1'b1
4'h0
--------
15'h3d1c
D
EOF
0dc
3
SOF
29'h4495
1'b0
1'b1
1'b1
4'h4
32'h45_4E_54_5F
15'h65c0
D
EOF
71d
4
SOF
29'h56a7
1'b1
1'b1
1'b1
4'h3
--------
15'h05f7
D
EOF
e0c
Table 3 CAN Frame
