Figure 2 Sine Wave #2
Square Wave
1. Square Wave #1
Frequency: 1 kHz
Amplitude: Approximately 3 Vpp
DC offset: 3.3 V
2. Square Wave #2
Frequency: 100 kHz
Amplitude: Approximately 3.3 Vpp
DC offset: 1.7 V
3. Square Wave #3
Frequency: 10 MHz
Amplitude: Approximately 3.3 Vpp
DC offset: 1.7 V
Attention
Use ground spring when probing square wave #3 to get the optimum signal fidelity
as shown below.
2 STB3 User Manual
