Instructions, use and maintenance manual Pag. 37/48
SRIZZA 40
TABLE EXPLODED VIEW 1
Pos. Q.ty Description Drawing
1 3 SCREW M8X23 DIN 603
2 1 UPPER PLATE SPZ 40 86153028-2
3 1 HIGH SUPPORT 26150038
4 1 6203 2RS 17-47-14 BEARING 13000324
5 1 17 MM HUB 01150012
6 1 MULTIGRIP BELT 12003951
7 1 PULLEY PLATE 85126023-2
8 1 DUCT PULLEY 50HZ 01153077
9 1 LOW SUPPORT 01153039
10 1 6206 2RS 30-62-16 BEARING 13000317
11 1 SPRIZZA CASING 86153031-8
12 1 SHAFT SUPPORT WHEEL 01153013
13 1 UPPER PLATE COVER 01153002
14 1 DUCT WHEEL 85153045-3
15 4 BUSHING 15005013
16 2 COUNTERWEIGHT 01153046-2
35 1 COUNTERWEIGHT ROPE 01153051-1
