Instructions, use and maintenance manual Pag. 40/48
SRIZZA 40
TABLE EXPLODED VIEW 3
Pos. Q.ty Description Drawing
1 12 COVERING 01153042
2 12 PLASTIC BLADES 01153003
3 12 BLADE SUPPORTS 01153004
4 4 DUST GASKET 19001001
5 4 BUSHING 25-28-L25 15005010
6 2 SUPPORT BUSHINGS 01153056
7 1 LOCK 01078124
8 1 MOBILE DISC 01078123
9 1 SPRING 08078071
10 1 HANDWHEEL 01078125
11 4 BUSHING 17-20-L15 01209034
12 1 SMALL SHAFT LEVER 01153025
13 1 SMALL SHAFT 01153021
14 2 BUSHING KU 08X10X10 15005013
15 1 BLACK WHEEL 01153046-2
16 1 MICRO LEVER 01153020-7
17 1 BUSHING 12-15 L12 15000512
18 1 MICRO CAM 01078004
19 1 SUPPORT PRESSURE 02153034-3
20 2 M12 FORK 23010202
21 2 BEARING 6201 12-32-10 13000312
22 1 RED KNOB 60 M12 14002208
23 1 SHAFT KNOB 01153017
24 1 SHAFT SUPPORT 01153012-5
25 1 RING DIN 17 14000817
25 1 SCREW M8x23 DIN 603
26 2 DISC SUPPORT 01153001
27 1 SUPPORT PLATE LOWER PLATE 01153011
47 1 COUNTERWEIGHT ROPE 01153051-1
