Instructions, use and maintenance manual Pag. 41/48
SRIZZA 40
EXPLODED VIEW 4
TABLE EXPLODED VIEW 4
Pos. Q.ty Description Drawing
1 3 BLACK KNOB 14002204
2 1 LIFTING LEVER 85153018-2
3 1 PLATE LEVER 85153043-4
4 1 LIFTING SUPPORT 85153019-1
5 1 BUSHING 12-15 L12 15000512
6 3 SCREW M8x23 01165022
7 1 BASE 86153030-6
8 2 ARM SUPPORT 85153022-1
9 2 BUSHING 20-25 L20 15000508
10 1 COLLAR DIN 20 14000820
