Instructions, use and maintenance manual Pag. 42/48
SRIZZA 40
EXPLODED VIEW 5
TABLE EXPLODED VIEW 5
Pos. Q.ty Description Drawing
1 1 UPPER COVER 86153041
2 1 RING 02153026-1
3 2 BLACK KNOB 14002201
4 2 AISI 430 STAINLESS STEEL RING 23013006
5 2 POLYPROPYLENE BELT 06000017-UL
6 2 M12 FORK 23010202
7 1 SPINDLE 01153037
