Service Manual BXT3-13/16/19ENGLISH
2.3 Maintenance table
Description Parts list
pos.
Action Light
applications
(Cycles*)
Avarage
applications
(Cycles*)
Heavy
applications
(Cycles*)
Remarks
Tensioning
wheel
46 Replace As required Wear part (see operating instructions)
Tooth plate 53 Replace As required Wear part (see operating instructions)
Knife 166 Replace As required Wear part (see operating instructions)
Shaft 180 Check 120‘000 100‘000 80‘000 Only for tool BXT3-19
Welding shoe 158 Check 120‘000 100‘000 80‘000 Check the toothing, ball guides and contact surface of the needle bearing for wear.
Replace if necessary.
Swivel bearing 153 Check 120‘000 100‘000 80‘000 Check the ball and knife guide for wear. Replace if necessary.
Sleeve 80 Check 120‘000 100‘000 80‘000 Check the toothing, turn or replace if necessary.
Toothed belt 162 Check
Replace
120‘000
240‘000
100‘000
200‘000
80‘000
160‘000
–
Needle bushing 157 Replace as
preventive
measure
120‘000 100‘000 80‘000 –
Belt pulley cpl. 127 Replace as
preventive
measure
120‘000 100‘000 80‘000 A defective or contaminated idle-run may damage the motor axle.
Bevel pinion cpl. 132 Replace as
preventive
measure
120‘000 100‘000 80‘000 A defective or contaminated idle-run may damage the motor axle.
Pressure
springs
81, 83, 170 Replace as
preventive
measure
240‘000 200‘000 160‘000 –
* For the read out of the cycle counter, see chap. 2.1.5.
