SIKA E2 User Manual

E2 / D2 Technical data
Technical changes reserved - 45 -
Display resolution
Measuring
range
bar
(kg/cm2)
mH2O PSI mbar kPa MPa
-1…3 bar -.999….3.000
-10.2…30.6 -15.0…45.0 -999…3000
-100.0…300.0 -/-
-1…40 bar -1.00….40.00
-10.2…408.2
-15…580 -/- -100…4000 -0.10…4.00
-1…60 bar -1.00….60.00
-10.2…612.2
-15…870 -/- -100…6000 -0.01…6.00
0…400 bar 0.0…..400.0 0…4082 0…5800 -/- 0…4000(x10) 0.00…40.00
0…700 bar 0.0…..700.0 0…7143 0…10000 -/- 0…7000(x10) 0.00…70.00
0…1000 bar 0.0…1000.0 0…10204 0…14500 -/- -/- 0.0…100.0
CAUTION! Material damage!
Exceeding the maximum overload values (Pmax) can lead to malfunctions and result in
the digital manometer being destroyed.
Overload values
Measuring range Overload Burst pressure
-1…3 bar 17 bar 20 bar
-1…40 bar 80 bar 400 bar
-1…60 bar 120 bar 550 bar
0…400 bar 800 bar 1700 bar
0…700 bar 1200 bar 2500 bar
0…1000 bar 1500 bar 2500 bar
