SIKA E2 User Manual

Technical data E2 / D2
- 44 - © SIKA • Ba_Ref-E2D2 • 11/2014
9 Technical data
The technical data of customised versions may differ from the data in these instructions.
Please observe the informations specified on the type plate.
Characteristics Reference E2 / D2
Measuring ranges input
- Piezzo resistive pressure cell
- DMS pressure cell
-1…3 bar
-1…40/60 bar and 0…400/700/1000 bar
Accuracy (25°C)
- Type E2
- Type D2
0.5% FS ±1 digit
0.1% FS ±1 digit
Sampling rate 10 ms
Internal resolution AD converter 12 bit = 4,096 steps
Temperature influence 0.05% FS / 10 K
Display/ LC Display:
- Actual value
- MIN/MAX or Full Scale(FS)
- Bar graph
x Sampling rate
- Backlight
4 ½ digits (15 mm)
4 ½ digits (8 mm)
33 segments (drag indicator function)
50 ms (20 measurements /s)
50 x 34 mm
Pressure units
bar, PSI, kPa, MPa, kg/cm
2
, mH2O
Electrical characteristics
Supply voltage Battery 2 x1.5 VDC AA (LR6 –AA), Alkaline (Mignon)
Battery life 1,500 hrs (without lighting)
Degree of protection (EN 60529) IP 67
Ambient conditions and process variables
Operating temperature 0…50 °C
Fluid temperature -20…+80 °C
Storage temperature -20…+60 °C
Relative humidity < 85%
Vibration IEC 60068-2-6 / 10…500 Hz / 5 g
Shock IEC 60068-2-29 / 11 msec. / 25 g
Pressure connection:
- Material
- Connection thread
- Gasket
Stainless steel 1.4404
¼ “ BSPP (ISO 1179-2)
NBR
Housing:
- Material
- Dimensions
Zinc cast (Rubber protection cap: TPE)
Ø = 79 mm, T = 33 mm
Weight 540 g
