SIKA EC mAV 2 User Manual

EC mAV 2 Technical data
Technical changes reserved - 45 -
9 Technical data
The technical data of customised versions may differ from the data in these instructions.
Please observe the information specified on the type plate.
Applicable to a temperature range from 18 °C to 28 °C, within one year after calibration.
9.1 Characteristics EC mAV 2
Characteristics EC mAV 2
Output
DC mA generation
*1
- Range
- Output range
- Resolution
- Accuracy
20 mA
0…22 mA
0.001 mA
± (0.05 % + 4 µA)
Transmitter simulation
*2
- Range
- Output range
- Resolution
- Accuracy
-20 mA
0…22 mA
0.001 mA
± (0.05 % + 4 µA)
Loop supply
*3
- Range
- Accuracy
24 V
± 10 %
Input
Voltage
*4
- Range
- Output range
- Resolution
- Accuracy
28 V
-0.2…28 V
0.001 V
± (0.02 % + 2 mV)
Current
*5
- Range
- Output range
- Resolution
- Accuracy
20 mA
-1…22 mA
0.001 mA
± (0.02 % + 4 µA)
Loop current
*6
- Range
- Output range
- Resolution
- Accuracy
20 mA
0…22 mA
0.001 mA
± (0.02% + 4 µA)
*1 max. load 1 kΩ at 20 mA.
*2 max. load 1 kΩ at 20 mA, power supply range 5…25 VDC.
*3 max output current up to 25 mA.
*4 input resistance about 1 MΩ.
*5 resistance about 20 Ω.
*6 providing 24 V loop supply.
