SIKA TD 32500 Operating Manual
If the alarm output 1 (2) is set as closed-circuit current alarm, it will be
separated from the voltage supply in the case of an alarm, thus switching-
off a connected consumer. If no alarm is present, the alarm output 1 (2) is
switched to the voltage supply and the connected consumer is switched-on.
Proceed as follows:
• The message „SET ALARM MODE – NO“ appears.
• Switch with the ▲ key to „YES“ and confirm with the
key.
• Select with the ▲ key one of the following operating modes:
OPEN CIRCUIT CURRENT
CLOSED CIRCUIT CURRENT
• Confirm the currently displayed operating mode of Alarm 1 and 2 by
pressing the
key.
• Continue to configure the individual parameters of Alarm 1 (2), return to
the menu start or quit the configuration menu.
This programming defines the source (flow rate, total flow (resettable), or -if
available- temperature), the type of alarm (minimum or maximum alarm),
the alarm point and the alarm hysteresis.
Parameters of alarm 1 and 2 are completely independent from each other
and can be individually configured. The programming process is identical
for the two alarms – consequently only programming alarm 1 is described
in the following, alarm 2 is shown in brackets.
Proceed as follows:
5
.2.4.2 Programming alarm 1 (2):
• The message „SET ALARM 1 (2) – NO“ appears.
• Switch with the ▲ key to „YES“ and confirm with the
key.
5
.2.4.2.1 Programming alarm source 1 (2):
• The message „SET ALARMSOURCE1 (2) – NO“ appears.
• Switch with the ▲ key to „YES“ and confirm with the
key.
• Select with the ▲ key one of the following sources:
ALARM OFF (disable Alarm 1 (2) )
FLOW
TOTAL (resettable volume counter)
TEMPERATURE (if available)
• Confirm the currently displayed source of Alarm 1 (2) by pressing the
key.
• Continue to configure the alarm type of Alarm 1 (2), return to the menu
start or quit the configuration menu.
