Bargraph:
graduation range from 0 up to 100%,
resolution: 2%,
applicable to flow rate, total flow, or temperature (optional)
Selectable physical measurement units for measuring values:
R
ate of flow:
l/min
l/h
m
3
/h
GPM(US)
GPM(UK)
T
otal flow:
l
m
3
GAL(US)
GAL(UK)
Temperature
:
°C
°F
Operating buttons:
2 infrared light reflex buttons, screened against outside light
Programming protection:
1. programmed parameters protected by access code
2.
ad
justable key lock
Alarm output (optional):
2 PNP open-collector transistor outputs:
applicable to flow rate, total flow, or temperature (optional),
adjustable as minimum or maximum alarm
adjustable alarm point
adjustable hysteresis
capacity: 1000 Ω with 24 VDC / 30 mA
alarm-signaling via LED with 3 mm diameter at front plate
