Siko MA10/4 User Manual

MA10/4-S Date: 21.02.2019 Page 4 of 28 Art.No. 87181 Mod. status 50/19
3 Display description
The MA10/4 has a backlighted 12-digit LC display. The display as well as the meaning of the
individual symbols is explained in the tables below.
3.1 Incremental and SSI versions
1
2
3
4
5
6
7
8
9
10
11
12
Digit
R
-
1
2
3
4
.
9
m
m
Position value
Digit
Symbol
Description
1
R
Incremental measure is active.
1
>
Upper limiting value exceeded (only for output circuit option). If
incremental measure as well as exceeding of the limiting value is active,
this will be displayed alternately.
1
<
Lower limiting value exceeded (only for output circuit option). If
incremental measure as well as exceeding of the limiting value is active,
this will be displayed alternately.
2-9
Measured value; negative values are displayed by "-" on position 2.
11-12
Unit of measure (programmable)
3.2 Rototional speed version
1
2
3
4
5
6
7
8
9
10
11
12
Digit
1
2
3
.
2
U
/
M
i
n
Position value
Digit
Symbol
Description
1
>
Upper limiting value exceeded (only for output circuit option). If
incremental measure as well as exceeding of the limiting value is active,
this will be displayed alternately.
1
<
Lower limiting value exceeded (only for output circuit option). If
incremental measure as well as exceeding of the limiting value is active,
this will be displayed alternately.
2-6
Measured value
8-12
Unit of measure (programmable)
3.3 Number of pieces version
1
2
3
4
5
6
7
8
9
10
11
12
Digit
R
-
1
2
3
4
5
S
t
k
Position value
Digit
Symbol
Description
1
R
Incremental measure is active.
1
>
Upper limiting value exceeded (only for output circuit option). If
