MA10/4-S
Date: 21.02.2019 Page 6 of 28 Art.No. 87181 Mod. status 50/19
5 Parameter description
At chapter 12 you will find a detailed parameter list showing all programmable parameters and
offering space for customer-specific programming values.
(in English, parameter LANGUAGE = "eng")
After entering the programming mode (see chapter 4) the parameters described below can be
configured. Depending on the settings selected, only the menu items that are relevant for the
application will be displayed.
5.1 Incremental version
ger or deu
(German)
eng (English)
Language
To choose the language in which the menu items are to
be displayed.
Attention! The term "SPRACHE" will be displayed first in
German.
0., 0.0, 0.00,
0.000, 0.0000
Positions after the comma
Display after 1 revolution
Value by which the display increases/decreases after 1
revolution of the encoder. If DPR: = 0, quadruple
evaluation of the encoder signal will take place
automatically.
Display divisor
Divisor by which the display accuracy is reduced
compared to the measuring accuracy. Example: Due to an
integer value ratio, the measuring resolution is
programmed to 1/1000 mm. The display, however, needs
a resolution of 1/10 mm only. -> The display divisor is
programmed to '100'.
Encoder pulses per revolution
If INCR: = 0, quadruple evaluation of the encoder signal
will take place automatically.
Counting direction
'i' clockwise increasing values
'e' anti-clockwise increasing values
I-lang, 0-lang, I-
kurz, 0-kurz
Input of logic and length of the encoder's reference signal
The encoder reference signal is output only once per
revolution.
'lang' index signal is wider than one increment; index is
linked with A and B signals.
'kurz' index signal is exactly as wide as one increment
'0' index signal with positive logic
'I' index signal with negative logic
