Siko MA10/4 User Manual

MA10/4-S Date: 21.02.2019 Page 7 of 28 Art.No. 87181 Mod. status 50/19
Display
Value range
Description
TRS:
n.open,
n.closed, hand
Reference switch
Type of reference value transmitter; can either be a
mechanical contact or a proximity switch.
'n.open' closing contact, which is normally open
'n.closed' opening contact, which is normally closed
'hand' Referencing arbitrarily via callipers independent of
A and B, index signal). The input is current-sinking and
edge-triggered.
REF:
-999999 ...
+999999
Reference point for the measuring system
Absolute datum point of the measuring system. This value
is set after system reference accord. to chapter 7.
OFF:
-999999 ...
+999999
Offset (displacement)
An be any value; used to influence the value displayed, e.
g. tool correction value.
RESET:
off, on, del.1s,
del.3s
Reset via keyboard enable
'off' reset function off
'on' reset function enabled
'del.1s' reset function enabled (press key for at least
1 sec.)
'del.3s' reset function enagled (press key for at least
3 sec.)
ABS/REL:
off, on
Incremental measurement enable
To switch from absolute measurement and zero-zetting to
relative measurement.
'off' function off
'on' function on
RE/OF.EN:
off, on
Reference/ offset value input enable
'off' reference/offset value correction off
'on' reference/offset value correction enabled
STO:
off, on
Actual value store
When switched off, the last displayed value is stored in a
non-volatile memory.
'off' Actual value memory off: when switched on, the
display must be calibrated (zeroed) (Display value is
flashing).
'on' Actual value memory on: when switched on, the last
measured value is displayed.
P-KEY:
3s, 5s, 10s,
20s, 30s
Programming keys delay
Delay of key when switching from input to
programming mode.
BAUD:
2400, 4800,
9600, 19200,
SIKON.3,
SCHALT
Interface's baud rate
'SCHALT' must be programmed for switching outputs,
'SIKON.3' for SIKONETZ3.
ADR:
1 ... 31
Adress setting for SIKONETZ3
Menu item will be displayed only if 'SIKON.3' is
programmed for 'BAUD:'.
UPL:
-999999 ...
+999999
For switching output: Input of the upper switching point
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'.
LOL:
-999999 ...
+999999
For switching output: Input of the lower switching point
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'.
