Siko MA10/4 User Manual

MA10/4-S Date: 21.02.2019 Page 10 of 28 Art.No. 87181 Mod. status 50/19
Display
Value range
Description
ADR:
1 ... 31
Address setting for SIKONETZ3
Menu item will be displayed only if 'SIKON.3' is
programmed for 'BAUD:'.
UPL:
-999999 ...
+999999
For switching output: Input of the upper switching point
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'.
LOL:
-999999 ...
+999999
For switching output: Input of the lower switching point
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'.
LIMIT.EN:
off, on
Enabling of modification of the limiting value
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'. Possibility of input/ modification
of the upper and lower limiting values in the input mode.
'off' Modification of limiting values disabled in input mode.
'on' Modification of limiting values enabled in input mode.
UNITS:
--, mm, cm, m,
km, in (inch), °
Unit of measure
Choice of the measurement unit to be displayed on
positions 11, 12 (see chapter 3 Display description).
DIS.ANGLE:
-5 ... +4
Display angle
Here, the contrast of the LC display can be set.
SET:
Encoder zeroing
Zeroing of the encoder (+ offset + calibration value) in
programming mode via key.
GDAT:
Position value of the encoder
Display of the actual encoder position.
CODE:
00000
Code input: for special functions
CONTROL:
off, on
Code input: for special functions
5.3 Speed version
(see chapter 9 for programming examples)
Display
Value range
Description
LANGUAGE:
ger or deu
(German)
eng (English)
Language
To choose the language in which the menu items are to
be displayed.
Attention! The term "SPRACHE" will be displayed first in
German.
INCR:
0 ... 59999
Encoder pulses per revolution
DEC:
0., 0.0, 0.00,
0.000, 0.0000
Positions after the comma
FAC:
00.0001 ...
99.9999
Calculating faktor
Freely selectable value, which influences the display.
CYCLUS:
0.1s, 0.5s, 1s,
1.5s, 2s, 3s, 5s,
10s
Cycle time
The display is refreshed after the programmed cycle time.
If short cycle times have been programmed
(recommended for high speed applications and high pulse
counts), modifications are quickly displayed. Increase
cycle time if display is irregular.
