Siko MA10/4 User Manual

MA10/4-S Date: 21.02.2019 Page 8 of 28 Art.No. 87181 Mod. status 50/19
Display
Value range
Description
LIMIT.EN:
off, on
Enabling of modification of the limiting value
Menu item will be displayed only if 'SCHALT' is
programmed for 'BAUD:'. Possibility of input/modification
of the upper and lower limiting values in the input mode.
'off' Modification of limiting values disabled in input mode.
'on' Modification of limiting values enabled in input mode.
UNITS:
--, mm, cm, m,
km, in (inch), °
Unit of measure
Choice of the measurement unit to be displayed on
positions 11, 12 (see chapter 3 Display description).
DIS.ANGLE:
-5 ... +4
Display angle
Here, the contrast of the LC display can be set.
CODE:
00000
Code input: for service only
CONTROL:
off, on
Code input: for service only
5.2 SSI version
Display
Value range
Description
LANGUAGE:
ger or deu
(German)
eng (English)
Language
To choose the language in which the menu items are to
be displayed.
Attention! The term "SPRACHE" will be displayed first in
German.
E-TYP:
multi, single,
linear
Encoder type
Determines the encoder type connected
'multi' multi-turn encoder
'single' single-turn encoder
'linear' linear measuring system
FORMAT:
no, Tree
Data format
Menu item will be displayed only if "multi" is programmed
for 'E-TYP:'
'no' Encoder data leftjustified (MSB first)
'tree' pine-tree (12 multiturn + 13 singleturn bits data
format)
S-BITS:
5 ... 19
Input of single-turn bits for multi-turn encoder
Menu item will be displayed only if "multi" is programmed
for 'E-TYP:'.
ENCOD.BIT:
5 ... 25
Input of the total encoder bit number
DEC:
0., 0.0, 0.00,
0.000, 0.0000
Positions after the comma
DPR:
0 ... 59999
Display after 1 revolution
Menu item will be displayed only if "multi" is programmed
for 'E-TYP:' Value by which the display
increases/decreases after 1 revolution of the encoder. The
maximum possible encoder resolution is displayed if DPR:
= 0. For 10 bit single-turn: 0 ... 1023
