Siko MA10/4 User Manual

MA10/4-S Date: 21.02.2019 Page 9 of 28 Art.No. 87181 Mod. status 50/19
Display
Value range
Description
DIVISOR:
1, 10, 100,
1000
Display divisor
Menu item will be displayed only if 'single' or 'multi' is
programmed for 'E-TYP:' Divisor by which the display
accuracy is reduced compared to the measuring accuracy.
Example: Due to an integer value ratio, the measuring
resolution is programmed to 1/1000 mm. The display,
however, needs a resolution of 1/10 mm only. -> The
display divisor is programmed to '100'.
FAC:
00.0001 ...
99.9999
Calculating faktor
Freely selectable value, which influences the display.
Menu item will be displayed only if "linear" is programmed
for 'E-TYP:'.
DIRECTION:
i, e
Counting direction
'i' clockwise increasing values
'e' anti-clockwise increasing values
DIRECT:
up (upwards)
down
(downwards)
Counting direction
Menu item will be displayed only if 'linear' is programmed
for 'E-TYP:'.
CAL:
-999999 ...
+999999
Calibration value for the measuring system
Absolute datum point of the measuring system. This value
is set after system calibrated accord. to chapter 7.
OFF:
-999999 ...
+999999
Offset (displacement)
Can be any value; used to influence the value displayed,
e. g. tool correction value.
RESET:
off, on, del.1s,
del.3s
Reset via keyboard enable
'off' reset function off
'on' reset function enabled
'del.1s' reset function enabled (press key for at least
1 sec.)
'del.3s' reset function enagled (press key for at least
3 sec.)
ABS/REL:
off, on
Incremental measurement enable
To switch from absolute measurement and zero-zetting to
relative measurement.
'off' function off
'on' function on
CA/OF.EN:
off, on
Calibration/offset value input enable
'off' calibration/offset value correction off
'on' calibration/offset value correction enabled
OUTPUT:
gray, bin
Output code
'gray' Encoder's data in Gray code
'bin' Encoder's data in binary code
TIMEOUT:
off, on
Time-out function
'off' Cable break recognition off
'on' Cable break recognition off
P-KEY:
3s, 5s, 10s,
20s, 30s
Programming keys delay
Delay of key when switching from input to
programming mode.
BAUD:
2400, 4800,
9600, 19200,
SIKON.3,
SCHALT
Interface's baud rate
'SCHALT' must be programmed for switching outputs,
'SIKON.3' for SIKONETZ3.
