Silberbauer Compact-Laser Series User Manual

 Compact - Laser Series CL plus Instructions for use
For your information only – it calculates automatically:
Therapy time depending of the position of the switches (in minutes : seconds):
(for blank cells, time is over 1 hour)
60 mW- Model:
Geriatrics
Pain therapy
new scars old scars
Gynecology, Surgery
Dermatology Sports, Physiotherapy
Children, depending of age
Dose (J/cm
2
): 
0,5 1 2 3 4 5 6 8
Power:
Acup. Child
5s 5s 5s 5s 5s 5s 5s 5s
25%
Acup. Adult
15s 15s 15s 15s 15s 15s 15s 15s
50%
1 cm
2
8s 17s 33s 50s 1m:7s 1m:23s 1m:40s 2m:13s 100%
2 cm
2
17s 33s 1m:7s 1m:40s 2m:13s 2m:47s 3m:20s 4m:27s 100%
5 cm
2
42s 1m:23s 2m:47s 4m:10s 5m:33s 6:57s 8m:20s 11m:7s 100%
10 cm
2
1m:23s 2m:47s 5m:33s 8m:20s 11m:7s 13m:53s 16m:40s 22m:13s 100%
20 cm
2
2m:47s 5m:33s 11m:7s 16m:40s 22m:13s 27m:47s 33m:20s 44m:27s 100%
30 cm
2
4m:10s 8m:20s 16m:40s 25min 33m:20s 41m:40s 50 min 100%
50 cm
2
6m:57s 13m:53s 27m:47s 41m:40s 55m:33s 100%
100 mW- Model:
Geriatrics
Pain therapy
new scars old scars
Gynecology, Surgery
Dermatology Sports, Physiotherapy
Children, depending of age
Dose (J/cm
2
): 
0,5 1 2 3 4 5 6 8
Power:
Acup. Child 5s 5s 5s 5s 5s 5s 5s 5s
25%
Acup. Adult 15s 15s 15s 15s 15s 15s 15s 15s
50%
1 cm
2
5s 10s 20s 30s 40s 50s 1min 1m:20s 100%
2 cm
2
10s 20s 40s 1min 1m:20s 1m:40s 2min 2m40s 100%
5 cm
2
25s 50s 1m:40s 2m:30s 3m:20s 4m:10s 5min 6m:40s 100%
10 cm
2
50s
1m:40s
3m:20s 5min 6m:40s 8m:20s 10min 13m:20s 100%
20 cm
2
1m:40s
3m:20s
6m:40s 10min 13m:20s 16m:40s 20min 26m:40s 100%
30 cm
2
2m:30s
5min 10min 15min 20min 25min 30min 40min 100%
50 cm
2
4m:10s
8m:20s
16m:40s
25min 33m:20s 41m:40s 50min 100%
For long treatments you can fix the laser into a tripod.
