Silberbauer Compact-Laser Series User Manual

 Compact - Laser Series CL plus Instructions for use
12 Technical Data:
Laser device, Series Compact - Laser CL plus xx - xxx :
Manufacturer and distributor: Prof. Dipl.Ing. Gerhard Silberbauer
Medizinische und physikalische Elektronik
Hießgasse 15, 1030 Wien, Österreich
0120
Intended use: for laser radiation of skin, mucosa and dental applications
Accessory: see page 0
Internal power source: Alkali-Mangan- battery or NiMH- battery, Size AA = LR 6
Classification: -protection level against electr. shock: Internal el. Power source
Part of application type BF
-protection level against harmful water invasion: Common device
-protection level during application together with explosive mixtures of
anaesthesias with air or with oxygen or laughing-gas:
Instrument is not to be used in an explosive atmosphere or with explosive mixtures
from anaesthesias with oxygen or laughing-gas!
-Kind of operation: Permanent operation
-due to EC – directive 93 / 42 / EWG: II A
- Laser class: je 2 M oder 3B
Divergence of beam: 0,33 rad +/- 10%
Therapy time: depending of position of rotary switches and model
automatically, +/-2%
Battery current: max. 1 A
Weight: without / with battery: 145 g / 173 g
Dimensions: 20 x 220 mm (D x L)
Model:
CL plus 60-658
CL plus 100-658
Nominal laser power +/-10% (mW):
60
100
Wavelength (nm):
658
658
Beam diameter at output (mm):
3,2
3,2
Admitted case temperature (operation):
10 bis 45
o
C
10 bis 45
o
C
Laser class:
2M
2M
Operating time with Alkali-Mangan-Batt. (hours):
3,5
2,5
Operating time with 2050 mAh- NiMH-Batt. (hours):
5,5
4,5
Mdell:
CL plus 100-78
Nennleistung +/-10% (mW):
100
Wellenlänge (nm):
788
Strahlenaustrittsdurchmesser(mm)
6,2
Zulässige Gehäusetemperatur (Betrieb):
10 bis 45
o
C
Laserklasse
3B
Therapiezeit mit Alkali-Mangan-Batt. (Stunden):
2,5
Therapiezeit mit 2050 mAh- NiMH-Akku (Stunden):
4,5
Interval for periodical inspection: 2 years
Rights for technical changes reserved! CL_plus_BED2_e.doc
