 Compact - Laser Series CL plus Instructions for use
3 Compact - Laser CL plus : View
1 2 3 4
Compact - Laser
CL plus xx-658
5 6
9
11
Ser.Nr.:
xxxx H
"Hidden Monitor"
10
7
8
1
Laser Point
7
Rotary Switch 2 (Dose)
2
Aluminium Body
8
Type Plate and Details
3
Lamp multi colour
(performance monitoring)
9
Socket for
Silberbauer Point Detector PS3
4
Push-button (Start / Stop)
10
Battery Cap
5
Lamp
(ready / battery low)
11
Laser Warning Label
6
Rotary Switch 1
(Function / Area)
3.1 Accessory
Optic Fibre, bent:
Direction of the
Las er B eam
Power loss with optic fibre: 25 % almost!
Power-reducing-tip:
Dire ction of th e
La s er B eam
Transmission 50%
