Compact - Laser Series CL plus Instructions for use
9 Laser inspection
The CL-Laser mini must be inspected at regular intervals of
2 years.
The inspection will be made in Vienna by Labor Silberbauer. Please, send
the Laser with all accessories and Instruments book!
If you want to get a spare device during the time of inspection, pleasse contact us.
9.1 Scope of inspection:
1. Examination of controlling elements
Due to danger of mechanical abrasion, the laser-button (4) must be checked and
also the rotary switches (6+7).
Scope of examination:
a) Control of strokes of rotary switch: The switch must be turned to its intended
positions. The blue lines at the top of the knobs must corrspond to the labeling.
b) Procedure for monitoring function of the rotary switches (6+7) and laser-button
(4):
Turn the rotary switch (6) into its off position.
Insert battery.
Press the laser-button.
No laser radiation has to emerge out of the instrument.
Turn rotary switch (6) in position “Acup. Child“ and immediately press the
laser-button (4) (within less then 2 secounds)
No laser radiation has to emerge out of the instrument.
Suddenly after you have turned the rotary switch into ist position the front
lamp (3) must flash for 2 secounds in orange colour.
Press button again after more than 2 secounds.
The laser must work for 5 s (check this time), at the beginning and at the end
of the time the warning signal must be audible.
2. Examination of Output Power:
Measuring Equipment required:
Measuring device for the laser output with a large Si-photo-diode (at least 10
x 10 mm) is well suited for the measurement of every monitoring phase of the laser
output and the wave-length of the CL mini Laser.
Specification:
Measuring accuracy: +/- 5%
Measuring Process: The output power is measured when the laser is turned on and
the sensor is hold perpendicular to the laser beam.
