Compact - Laser Series CL plus Instructions for use
5 Possible dysfunctions of the laser
Attention must be paid to the existing danger involved in meddling
with a damaged instrument and being exposed to dangerous laser-
radiations!
If the green lamp (5) doesn’t glow after switching in the laser:
Battery is totally empty; turn out battery cap, put out battery and replace it
by a charged one; close battery cap.
If the yellow lamp (3) diesn’t glow after pressing the start buttom, then
release buttom and check:
are there several secounds since you switched in the device? ( it will last 2
secounds delay time until the laser can be started)
is the green lamp (5) blinking?
It is enough to charge the empty battery for several minutes to make a short
treatment!
If the lamp (3) blinks red, so the laser power is too low for any reason. If this lamp
glows permanently, either the laser power was too high or the case was too hot; the
device has made a security switchoff. You have to turn the rotary switch 1 (6) into
ist off- position to resert the device. (Only after switching off respectively after
cooling the device may be used again. If the red lamp glows again please bring
or send the device to our service station!
If the laser doesn’t work althouigh the battery is charged, so please
do not use the device and do not make any further attempts, but bring or
send the laser and the battery to our service station for checking!
Fluid traces or small colorless or white crystals at the battery or at contacts indicate
that a battery or a rechargeable battery has leaked and the contacts do not work. In
this case, please send the device to the service for professional cleaning!
