Silver 5 Thread User Manual

To insert: Insert the needle in hole A of the needle
changing tool so that the flat side B of the needle is
opposite face of the tool. Insert the needle as far as it
will go into the needle holder (you may have to push
a little harder by hand) and tighten the retaining
screw. Remove the needle changing tool.
Lower the presser foot and raise the
needle(s) to its/their highest position. Take the needle
changing tool out of the accessory box and push it up
over the needle as far as it will go. Loosen (but do not
remove) the needle s retaining screw with the allen
key and pull the needle out from below.
To remove:
10
Changing a needle
Turn off at the power switch
A
B
The uses EL X 705 CF overlock needles.
