Mixing bowl with food processor
NOTE
► Use the diagrams on the fold-out page for assembly assistance!
1)
Fit the drive shaft i to the shaft holder.
2) Place the mixing bowl u onto the motor block o so that the arrow is
pointing at the symbol
and rotate the mixing bowl u until the arrow is
pointing at the symbol
. The mixing bowl u is now fi xed.
3) Select a suitable disk 0 q w (see chapter “Working with the food proces-
sor”) and insert it into the disk adapter e:
– if a diff erent disk is still installed: Press the metal tab of the disk outwards
so that it slides o
ver the locking mechanism on the disk adapter e. You
can now remove the disk.
– Insert the new disk with the narrower side fi rst into the recess in the disk
adapter e and push the disk fi
rmly downwards so that it engages and
is fi rmly seated.
4) Place the disk adapter e with the disk fi tted onto the drive shaft i.
5) Put the lid 3 onto the mixing bowl u so that the arrow on the lid 3 points
to the symbol
on the mixing bowl u. Then rotate it until an audible
“click” is heard and the arrow is pointing to the symbol
.
6) Slide the pusher 1 into the fi lling shaft 2.
7) Insert the plug into the mains power socket.
Blender
NOTE
► Use the diagrams on the fold-out page for assembly assistance!
1)
Place the blender onto the motor block o in a central position so that the
arrow on the holder with mixing knife 9 is pointing at the symbol
.
2) Turn the blender until the arrow is pointing at the symbol .
