Silvercrest KH 2450 - Top; Right; Bottom; L 5.6 Bottom

10
5.3 Top
o
Memory card slot » SD/MMC« (for SD/MMC memory cards)
a
Button »ON/OFF« (for switching the voice recorder on and o)
s
Microphone jack socket »MIC « (for connecting an external microphone
with a . mm jack plug)
d
Status lamp »DICT «
f
Microphone »MIC
« (internal microphone of the voice recorder for dictation
recording)
5.4 Right
g
Button » DICT«
h
Multi-function slider for the functions
Ú
» FFWD« (fast forward at playback)
Ú
» STOP« (stop dictation recording/playback)
Ú
» START« (start dictation recording/playback)
Ú
» REW« (fast rewind at playback )
j
Slider » HOLD« (Activate/Deactivate the key lock)
5.5 Bottom
k
USB interface » « (to connect the voice recorder to a PC)
5.6 Bottom
l
Battery compartment »OPEN/BATT «
;
Button »RESET«
. Preparing the voice recorder for use
1
Carefully remove the voice recorder from the packaging.
2
Only for battery/cell operation: Open the battery compartment
l
at the rear
of the voice recorder. Insert …
Ú
the two supplied cells, resp.,
Ú
two batteries of the type AA Mignon . V or
Ú
batteries of the type AA/LR . V.
Be sure to insert the batteries/cells with their correct polarities. The correct
polarity is indicated inside the battery compartment. When done, close and
secure the battery compartment.
