SIM800C_Hardware_Design_V1.00 14 2014-10-30
3.2. Pin Description
Table 5: Pin description
Pin name
Pin number
I/O
Description
Comment
Power supply
VBAT
34,35
I
Power supply
VDD_EXT
40
O
2.8V power output
If these pins are unused,
keep open.
GND
8,13,19,21,27,30,
31,33,36,37
Ground
GND for VBAT recommend
to use 36,37pin
Power on/down
PWRKEY
39
I
PWRKEY should be pulled low at
least 1 second and then released to
power on/down the module.
Internally pulled up to
VBAT.
Audio interfaces
MICP
9
I
Differential audio input
If these pins are unused,
keep open.
MICN
10
SPKP
11
O
Differential audio output
SPKN
12
GPIO
NETLIGHT
41
O
Network status
STATUS
42
O
Power on status
Serial port
UART1_DTR
6
I
Data terminal ready
If these pins are unused,
keep open.
UART1_RI
7
O
Ring indicator
UART1_DCD
5
O
Data carrier detect
UART1_CTS
4
O
Request to send
UART1_RTS
3
I
Clear to send
UART1_TXD
1
O
Transmit data
UART1_RXD
2
I
Receive data
UART2_TXD
22
O
Transmit data
UART2_RXD
23
I
Receive data
Debug interface
USB_VBUS
24
I
Debug and download
If these pins are unused,
keep open.
USB_DP
25
I/O
USB_DN
26
I/O
ADC
ADC
38
I
10bit general analog to digital
converter
If these pins are unused,
keep open.
SIM card interface
SIM_VDD
18
O
Voltage supply for SIM card.
Support 1.8V or 3V SIM card
All signals of SIM interface
should be protected against
