SIM Tech SIMCom SIM800C User Manual

Smart Machine Smart Decision
SIM800C_Hardware_Design_V1.00 43 2014-10-30
6. Electrical, Reliability and Radio Characteristics
6.1 Absolute Maximum Ratings
The absolute maximum ratings stated in following table are stress ratings under non-operating conditions.
Stresses beyond any of these limits will cause permanent damage to SIM800C.
Table 28: Absolute maximum ratings
Symbol
Min
Typ
Max
Unit
VBAT
-
-
4.5
V
Current
0
-
2.0
A
USB_VBUS
-
-
12
V
I
I
*
-
-
16
mA
I
O
*
-
-
16
mA
*
These parameters are for digital interface pins, GPIO, and UART.
6.2 Recommended Operating Conditions
Table 29: Recommended operating conditions
Symbol
Parameter
Min
Typ
Max
Unit
VBAT
Power supply voltage
3.4
4.0
4.4
V
T
OPER
Operating temperature
-40
+25
+85
℃
T
STG
Storage temperature
-45
+90
℃
6.3 Digital Interface Characteristics
Table 30: Digital interface characteristics
Symbol
Parameter
Min
Typ
Max
Unit
V
IH
High-level input current
2.1
-
3.1
V
V
IL
Low-level input current
-0.3
-
0.7
V
V
OH
High-level output voltage
2.4
-
-
V
V
OL
Low-level output voltage
-
-
0.4
V
Note: These parameters are for digital interface pins, such as keypad, GPIO and UART.
6.4 SIM Card Interface Characteristics
Table 31: SIM card interface characteristics
Symbol
Parameter
Min
Typ
Max
Unit
I
IH
High-level input current
-1.0
-
1.0
uA
I
IL
Low-level input current
-1.0
-
1.0
uA

SIM Tech SIMCom SIM800C Specifications

General

Module Type	GSM/GPRS Module
Frequency Bands	GSM 850/900/1800/1900 MHz
GPRS mobile station	Class B
Compliant to GSM phase	2/2+
USSD	Supported
Operating Temperature	-40°C to +85°C
Product Type	GSM/GPRS Module
GPRS Class	Class 12
Coding scheme	CS-1, CS-2, CS-3 and CS-4
SMS	Text and PDU modes
Interfaces	UART, SPI, I2C, GPIO, ADC
Power Supply	DC
Supply voltage range	3.4V to 4.4V
Transmitting power	Class 4 (2W) @850/900MHz, Class 1 (1W) @1800/1900MHz
Data Rate	GPRS multi-slot class 12: max. 85.6 kbps (uplink & downlink)
TCP/IP	Embedded TCP/IP stack
