• The machine is furnished with a pedal to confirm and execute the manoeuvre, thus avoiding the upper parts
to be trapped while the machine is running.
• The work area is protected by a safety guard to limit possible accidents. This guard is transparent to allow
observation of the material being bent, avoiding getting to the upper parts of the bending area.
• The machine is painted in oven with a highly resistance, anti-corrosion epoxy polyester paint.
• The original, electrical equipment is in conformity with the EC safety norms.
• The COMBI model is supplied with a cutting jaw with a safety metal guard connected to an electrical
protection system. When this safety guard is lifted, the machine stops working.
3. PARTS OF THE MACHINE.
1. SAFETY VISOR BENDING PLATE.
2. MINOR ADJUSTMENT HANDLE.
3. CHASIS.
4. SAFETY GUARD FOR CUTTING HEAD.
5. GEAR BOX.
6. MOTOR PLAQUE.
7. MOTOR.
8. TRANSMISISON BELTS.
9. ELECTRICAL BOX.
10. ACCESS DOOR HANDLE.
11. EMERGENCY STOP.
12. BENDING PLATE FOOT PEDAL.
13. BENDING PLATE.
14. SIDE MANDREL ADJUSTMENT.
15. ELECTRICAL SOCKET.
16. CUTTING HEAD.
17. FIXED CUTTING BLADE.
18. MOVING CUTTING BLADE.
