13.6 ICON LEGENDS MEANING.
The meaning of the different icons used in the application is as follows:
Language selection. Access to automatic mode.
Access to test mode. Access to help mode.
Access to time counter. Horizontal / vertical shift button.
Session start. End of session.
Access to codes to extend Access to time setting.
usage time. ( (blocked on user mode).
Access to timer configuration Machine ready.
(blocked on user mode).
Active alarm. Emergency button malfunction.
Motor malfunction. Open front door.
Protective guard lifted. Jaw guard open (COMBI models).
Timer by end date. Timer by time of use.
