4.5 Unscheduled maintenance
If replacing the electronic board , the user MUST set the parame-
ters as indicated in the table and in the sequence shown.
Type No. Description
Setting for
Brava
Slim BF
25 30
PAR 01
Index showing boiler power
in kW
0 = 24; 1 = 30
0 1
PAR 02
Hydraulic configuration
0 = rapid
1 = storage tank with thermo-
stat or heating only
2 = hot water t
ank with sensor
3 = bithermic
4=instant with solar power
input
0
PAR 03
Gas Type Configuration
0 = G20; 1 = LPG
0 or 1
PAR 04
Combustion configuration
0 = sealed chamber with com
-
bustion control
1 = open chamber with smoke
thermostat
2 = Low NOx
0
To enter "Parameter setting and display"refer to the indica-
tions provided in the specific section.
Onc
e the par
ameters in the table have been set, you must carry
out the "Automatic calibration procedure".
If the
gas valve and/or the ignition/detection electrode and/or the
fan are replaced, the user must still carry out the entire phase
of "Automatic calibration procedure" described in the specific
section.
4.6 Malfunction codes and possible solutions
LIST OF MALFUNCTION/FAULT ALARMS
Type No. Fault Solution
ALL 01 Smoke thermostat
- Contact the Technical Assis-
tance Centre
ALL 02
Low wat
er pressure
in system
- Restore pressure
- Check for any leaks in the
system
ALL 03
High water pres
-
sure in system
-
Empty the system via the
drain valve on the hydrau
-
lic assembly and bring the
pr
es
sure to approximately
1.2 bar
ALL 04
Domestic hot water
sensor fault (return
sensor fault for T
models)
- Check connections
- Check the sensor is working
ALL 05
Delivery sensor
fault
- Check connections
- Check the sensor is working
ALL 06 No flame detection
- Check the integrity of the
electrode and check that it is
not grounded
- Check gas availability and
pressure
- Check the integrity of the gas
valve and the card
ALL 07
Sensor or safety
thermostat inter
-
venes
-
Check the sensor or thermo
-
stat connections
-
Deaerate the system
- Check the bleed valve
- Replace the sensor or the
thermostat
- Check that the pump impel-
ler is not blocked
ALL 08
Fault in the flame
detection circuit
- Check the integrity of the
electrode and check that it is
not grounded
- Check the integrity of the gas
valve and the card
Type No. Fault Solution
ALL 09
No water circulating in
the system
- Check the rotation of the
pump rotor
- Check the electrical con-
nections
-
Replace the pump
ALL 10 Auxiliary sensor fault
- Check PAR 02 "hydraulic
configuration"
- Check the electrical con-
nection
ALL 11
Gas valve modulator
disconnected
- Check the electrical con-
nection
ALL 12
Domestic hot water
sensor fault in tank
mode
- Set the parameter PAR 04
(Combustion configuration)
to 0
ALL 13
Smoke probe interven
-
tion
- Check the sensor is working
- Replace the smoke probe
ALL 14 Smoke probe fault
- Replace the smoke probe
- Check the electrical con-
nection of the smoke probe
- Contact the Technical Assis-
tance Centre
ALL 15
Fan check cable dis
-
connected
- Check the connection cable
between the fan and the
board
ALL 18 Condensate level fault
- Check for any clogging in
the pipe which takes the
condensate to the siphon
- Check that the siphon is not
clogged
ALL 28
Maximum number of
consecutive resets
reached
- Wait 1 hour and try un
-
blocking the board again
-
Contact the Technical
Assistance Centre
ALL 30
Return sensor fault
(boiler sensor fault for
T models)
- Replace the return probe
- Check parameters
- Contact the Technical
Assistance Centre
ALL 37
Fault due to low net-
work voltage
-
Check the voltage
- Contact your network
provider
ALL 40
Incorrect network
frequency detected
- Contact your network
provider
ALL 41
Flame loss more than
6 consecutive times
- Check the ignition/detec
-
tion electrode
-
Check the gas supply
(open valve)
- Check mains gas pressure
ALL 42 Button fault
- Check that buttons are
working
ALL 43
Open Therm commu
-
nication fault
-
Check the OT electric
connection
ALL 44
No flame valve open-
ing time sum anomaly
-
Check for the presence
of water hammer on the
hot water system and, if
present, mount a water
hammer arrestor
- Check for any abnormal
requests on the room
thermostat
- Contact the Technical
Assistance Centre
ALL 56
Lock for ∆T delivery/
return over max limit
(open vent)
- Contact the Technical
Assistance Centre
ALL 57
Lock for flow temper
-
ature (FT) check (open
vent)
-
Contact the Technical
Assistance Centre
ALL 62
Self-calibrating proce
-
dure is required
-
Carry out the self-cali
-
brating procedure (see the
specific section)
ALL 72
Inc
orr
ect positioning
of the delivery sensor
- Check delivery sensor
operation and position
ALL 74
Second delivery sen
-
sor fault
-
Check second delivery
sensor operation and
position
ALL 77
EV2 SGV current max/
min absolute limits
error
- Check gas valve and board
ALL 78
EV2 SGV current upper
limit error
- Check gas valve and board
ALL 79
EV2 SGV current lower
limit error
- Check gas valve and board
