Simfer Good - Oven Door Cleaning and Assembly

31
10.1. Cleaning and Assembly of the Oven Door
To replace the oven door again; reverse the procedure for removing
the door.
Figure 10
Figure 10.1 Figure 10.2 Figure 11.1 Figure 11.2
Figure 11
Open the door
completely by
pulling the oven
door toward you.
Then, as shown
in Fig. 10.1,
pull the hinge
lock up with a
screwdriver
and perform
the unlocking
operation.
As shown in Fig.
10.2, bring the
hinge lock to
the maximum
angle. Bring
both hinges that
connect the oven
door to the oven to
the same position.
Then, close the
oven door you have
opened so that
it shall lean against
the hinge lock
as shown in
Fig. 11.1.
To remove the oven
door, hold the door
with both hands
when it is at a
close level to the
closed position,
and pull it up as
shown in Fig. 11.2
.
GB
