Simmons SDHB2 - MIDI Implementation Chart

SDHB2
www.simmonsdrums.net
midi implementation chart
Function Transmitted Recognized Remarks
0:YES
X:NO
Basic Default 10ch 1–16
Channel Changed X X
 Default X X
Mode Messages X X
 Altered ************** **************
Note  0–127 0–127
Number: Truevoice ************** 0–127
Velocity Noteon 0(99H,V=1–127) 0(9nH,V=1-127)
 Noteo 0(99H,V=0) 0(8nHor9nH,V=0)
After Key’s X X
Touch Channel’s X X
PitchBend  X 0
Control 0 X 0 BankSelect
Change 1 X 0 Modulation
 4 0 0 FootController
 5 X 0 PortamentoTime
 6 X 0 DataEntry
 7 X 0 Volume
 10 X 0 Pan
 11 X 0 Expression
 64 X 0 SustainPedal
 65 X 0 PortamentoON/OFF
 66 X 0 SostenutoPedal
 67 X 0 SoftPedal
 80 X 0 ReverbProgram
 81 X 0 ChorusProgram
 91 X 0 ReverbLevel
 93 X 0 ChorusLevel
 100,101 X 0 RPNLSB,MSB*
 120 X 0 AllSoundOFF
 121 X 0 ResetAllController
 123 X 0 AllNotesOFF
ProgramChange 0 0
System Exclusive X 0
System :SongPosition X X
Common :SongSelect X X
 :Tune X X
System :Clock 0 X
RealTime :Commands 0 X STARTandSTOPonly
Aux :LocalON/OFF X X
 :AllNotesOFF X X
Messages :ActiveSense 0 X
 :Reset X X
*ValidRPN#0,1,2
