Simmons SDHB2 - Assembly

SDHB2
www.simmonsdrums.net
TheSDHB2SimmonsElectronicAdd-OnPackisauniqueproductthatallowsyoutoseamlesslymixyouracousticdrumsetwith
theuniqueelectronicdrumcapabilitiesoftheSimmonsSD7K.
This kit contains:
Attaching the Drum Module
Spread the stand’s legs and insert top of stand into base.
1.AttachthemetalrodtotheDrumModule.
2.TightenthewingscrewsecurelyontheDrumModule.
3.Attachthemetalrodtotheholderclamponthe
sidearm(L1)andadjusttheposition.
4. Tighten the wing nut on the holder clamp.
Attaching Pads to clamps
TheSDHB2padscanbemountedontheclampsandattachedtotheenclosedstandortoanyotherstandonyourdrumsetfor
maximumexibility.Toconnectthepads,attachthepadtotheL-Armontheclamp.
assembly
2x3’and2x8’cablestoconnectthe
pads and the triggers to the Brain Module
Stand and clamps to hold
the Brain Module and pads
Brain Module
2xSimmonsSDPSZPPro9”pads
2xSimmonsSDADTPiezotriggers
wing screw
metal rod
