Simoco SDM630 Series - Table 7: Icon Details

ICON
INDICATION
Connecting icon. Shown when a text message is being sent and the connection is
in progress.
Connection Fail icon. Shown when a text message transmission has failed.
The asterisk symbol indicates whether the radio has been “called” or is in the
“on-call” state.
Table 7: Icon Details.
Doc Number: TNM--U-E-0108 ISSUE 1.5 Page 29
