3. EXPLOSION VIEW
Explosion View / Parts List
4. PARTS LIST
Item # Part Name Qty. Illustration / Part #
*A Hand crank 1
VE01-002-0035
B Cord bracket 1
VE06-030-0001
C Gun holster 1
VE06-030-0002
D
Detergent
bottle & cap
1
VE06-050-0000
E
Tips kit (3 tips
& turbo)
1 set
VE05-031-0000
F
Quick-connect
wand
1
XE05-000-0003
Item # Part Name Qty. Illustration / Part #
G Gun assembly 1
XE03-020-0003
H
Cleaning
needle
1
VE05-060-0001
I
High-pressure
hose
1
VE06-000-0003
*J Water lter 1
VE05-030-0004
K
Eavestrough
cleaning kit
1 set
VE06-090-0001
*Hand crank and water lter come
pre-attached on the machine.
I
H
G
E
F
J
K
A
B
C
D
