8
5. ASSEMBLY INSTRUCTIONS (cont.)
5.4 Assembly Steps (cont.)
F
E1 E2 E3
E4
Attach the desired spray tip to the wand. The spray tips (E)
are for the following purposes:
• E1 (Red - 0º): For tough spots and grimes (e.g.,
concrete surfaces);
• E2 (Yellow - 15º): Delivers balanced pressure & ow for
general cleaning;
• E3 (Black): Low pressure / to apply detergent;
• E4 (Turbo): To clean larger areas more eciently.
To install spray tips, gently slide the collar back before
inserting the tip (see below).
G
1
3
2
(When using detergent)
1. Fill the detergent container with detergent.
2. Firmly close the detergent bottle cap.
3. Attach the container to the pressure washer’s container
storage area.
H
Connect garden hose to the inlet adapter.
